Truoba Class 316

  2754 sq ft        3 Bed        2.5 Bath

House Plan Construction Drawings

What's included?
Clear
House plan design
Customize this house plan

Download House Plan brochure

Request brochure

How much does it cost to build?

Request cost estimate

Rate this plan

Truoba Class 316 house plan, secon floor house floor plan

Plan

2754 sq/ft
House Area
525 sq/ft
Garage Area
94’-5″ X 69′-8″
Dimensions
  • Open floor plan
  • Living area linked to the porch
  • Open space to the second floor
  • Fireplace
  • Master Bedroom separate from other bedrooms
  • Walk-in closet
  • Private terrace
  • Home office – studio
  • Mud room
  • Walk-in pantry
  • Storage space
  • Covered front porch
  • Covered rear porch
  • Outside fireplace
Customize this plan Check how floor plan fits your property for FREE

Area

House area: 2754 sq. ft.

Garage area: 525 sq. ft.



Dimension

Width: 94′-5″

Depth: 69′-8″

Height: 29′-9″



Exterior Wall

Framing: 2″x6″ stud wall

Wall finish: Vinyl siding

Possible different wall finishes: Wood siding, brick veneer, stucco, stone, fiber cement, etc.

Insulation: 6″ (applicable for additional insulation)



Foundation

Type: Slab and crawl. Additionally, choose basement foundation

Insulation: 8″-10″ (applicable for additional insulation)



Roof

Primary pitch: 5.4/12 (24°)

Secondary pitch: 6.4/12 (28°)

Roof framing: Rafters

Insulation: 12″ (applicable for additional insulation)



House Interior

Ceiling height: from 9′

Main living area ceiling height: Pitch bottom 15′-5″, pitch top 21′

The place to unwind

Modern farmhouse

This design is one of the house plans that are a combination of traditional American farmhouse and minimalistic contemporary style architecture. It reflects the needs of contemporary living by giving you diverse inside spaces, perfect for spending quality time with the family or having friends over. All main ground-floor spaces are connected to the open outside porch, that can be used for relaxing or barbecuing.

Lofty space

The floor plan is divided into a few different zones. The main living area features a double story ceiling which opens up to the second-floor studio and is great for communal activities as well as working in private. The master bedroom features a large en suite bathroom and has a closet situated further away from the main bedroom area to give privacy and insulation from outside noises. The master suite is situated parallel to the living area to catch the best views of your modern house lot.
