One of the quintessential scenes of summer consists of the kids playing in the yard, while the parents sip beverage on the porch. This type of all-American scene doesn’t have to be just a dream, though. With the house plans that have a porch you can enjoy summer nights if you bundle up on your porch. Transform your every day living with wrap around porch house plans. You’ll find there are a number of benefits to adding on a porch.
What's included in House Plan Set drawings?
Slab | Crawl | On request - Basement, Pier & Beam, etc.
General foundation design showing foundation layout with structural elements. There are three types of foundation to choose from: slab, crawl, and basement.
As in all building locations ground condition varies, your local structural engineer would need to approve foundation design and specify foundation structural elements.
Shows the layout of plumbing fixtures with specifications.
Indicates house layout with dimensioned walls, doors and windows.
Roof Construction Plan
Shows the layout and dimensions of the required roof structure such as rafters and beams. As show load requirement is different in each location your local structural engineer would need to approve and specify roof structural elements.
Dimensioned roof layout indicating slopes, roof areas, chimneys, and decorative elements.
Cut through the building showing detailed floor, wall, and roof construction elements. Indicating room ceiling heights and structural element heights.
Shows all sides of the house indicating building elements with its heights, specified materials, and all decorative elements.
Detailed house cut-away with outline specifications.
Floor plan layout indicating locations of electrical elements such as lightning, switches, outlets, etc.
Indicates location and specifications for heating, ventilation and air conditioning.
Representative floor plan layout indicating room sizes and suggested furniture layout. Useful during the interior design stage.
Door and Window Schedule
List or all windows and doors with indicated specifications for manufacturer.
Plumbing, electrical and mechanical specifications
