Download Free House Plans PDF
Slab and Crawl foundation showing foundation layout with structural elements.
Shows the layout of plumbing fixtures with specifications.
Indicates house layout with dimensioned walls, doors, windows, etc.
Roof Construction Plan
Shows roof layout and structural specifications.
Dimensioned roof layout indicating slopes, roof areas and decorative elements.
Cut through the building showing detailed floor, wall, and roof construction elements with specifications
Shows all sides of the house facade indicating building elements, specifications and all decorative elements.
Detailed house cut-away with outline specifications.
Home plan layout indicating locations of electrical elements.
House plan layout indicating room sizes and suggested furniture layout.
Door and Window Schedule
List or all doors and windows with indicated specifications for manufacturer.
House area: 480 sq. ft.
Framing: 2″x6″ stud wall
Wall finish: Wood siding
Roof pitch: 2/12 (9.5°)
Roof framing: Rafters
Ceiling height: 9′
Living room ceiling height: from 9′ to 11′
