Truoba 320

2354 sq/ft     3 Bed    2.5 Bath

House plan design
Customize This House Plan

House Construction Drawings

$

How Much Will It Cost To Build?

Get Cost To Build Report

How Much Will It Cost To Build?

Get Cost To Build Report

Truoba 320

2354 sq/ft     3 Bed    2.5 Bath

House plan design
Customize This House Plan

House Construction Drawings

$



Rate this plan

3.9/5 - (187 votes)

Floor Plan

2354 sq/ft

House Area

676 sq/ft

Garage Area

82′-6″ X 63′-10″

Dimensions
Customize This Plan

Check how floor plan sits on your plot for FREE

  • Open floor plan
  • Living area linked to the porch
  • Main floor master bedroom
  • Walk-in closet
  • Carport
  • Pantry
  • Storage space
  • Covered front porch
  • Covered rear porch

Area

House area: 2354 sq. ft.

Garage area: 676 sq. ft.



Dimension

Width: 82′-6″

Depth: 63′-10″

Height: 24′-2″



Exterior Wall

Framing: 2″x6″ stud wall

Wall finish: Brick veneer and stucco

Possible different wall finishes: Wood, vinyl, stucco, stone, fiber cement, etc.

Insulation: 6″ (applicable for additional insulation)

Foundation

Type: Slab and crawl. Additionally, choose the basement foundation

Insulation: 8″-10″ (applicable for additional insulation)



Roof

Primary roof pitch: 4/12 (18o)

Secondary roof pitch: 2/12 (10o)

Framing: Joists (2″x10″)

Insulation: 12″ (applicable for additional insulation)

Snow load: 30 PSF



House Interior

Ceiling height: 10′

Main living area ceiling height: from 16′ to 22′

Balanced Living

Family Space

This modern house plan reflects the needs of contemporary living by giving you a diverse inside layout. House plans like these are divided into several different zones, creating designated spaces for all events and family members.

Room for Life

The left wing of the house accommodates a main living area and a dining room with a kitchen conveniently located on the side. The master bedroom with a large bathroom and an open closet are tucked away in the right wing of the house, giving you peace, privacy, and view to the best view of the open lot. This modern house also includes second and third bedrooms that can be easily transformed into a home office or a hobby room.
